Working Voltage

208 - 240 VAC, 50/60Hz, Single Phase

110V -220V AC Power plug is not included

Max. Power Consumption

        300W

Front Panel & Tension Control

Infinite switch for various tension control 0~20N

Tension adjustable torque motor for active reeling

Friction resistant passive unreeling

Motor Type

The use of brushless motor ensures no sparking in the Ar gas environment

Reeling Width

< 250mm width for flexible substrate material

Traverse Speed

The film traverse speed is dependent on its calendering speed, normally <1.5 meters/min

Roller's O.D

3 inches

Reeling/Unreeling Roll Diameter

Max. 300mm

Compliance

CE certified

Warranty

Two years limited warranty with lifetime support

Net Weight

        300 kg
