Roll to Roll Pressure Controlled Hydraulic Rolling Press Machine
Model Number:
TMAX-YY-300Dimension(L*W*H):
1500mm*800mm*1500mmNet Weight:
800kgCompliance:
CE CertifiedWarranty:
Two Year Limited Warranty With Lifetime SupportPayment:
L/C D/A D/P T/T Western UnionDelivery Time:
5 days
- WhatsApp : +86 13003860308
- Email : David@tmaxcn.com
- Email : Davidtmaxcn@gmail.com
- Wechat : 18659217588
Previous:
Dia 200mm Roll to Roll Pressure Controlled Hydraulic Roller PressNext:
Roll to Roll System for Table Top Calender Machine up to 250 mm Width
Roll to Roll Pressure Controlled Hydraulic Rolling Press Machine
1
TMAX-YY-300 Hydraulic Roller pressure machine is
an Automatic
Battery Electrode Rolling Press System with precision digital
pressure control . The pressure can be adjusted easily by touch screen. It
biggest roller press width is 300mm.
2 It is with tension controlled feeding
and winding devices with the electric rolling press machine,
which can roll to roll continuous Electrode calendering, suitable
for battery electrode roll to roll calendering for
pilot scale research work.
3 You can also just choose the Hydraulic roller press machine without feeding and winding device as model TMAX-YY-300
SPECIFICATIONS
Model |
Roll to Roll Pressure Controlled Hydraulic
Rolling Press Machine TMAX-YY-300 |
Function |
Calender electrode |
Calender Thickness |
0.01-3.5mm adjusted |
Calender Width |
Max 300mm |
Calender Pressure |
Max 350KN |
Speed |
1-3m/min |
Working Roller |
Diameter 200mm, 9Cr3Mo materials |
Roller Width |
320mm |
Calender Model |
Hydraulic press |
Accuracy |
0.003mm |
Rolling Press Machine Power |
4KW |
Winding and Unwinding power |
0.55KW |
Tension Control |
Absolute value photoelectric encoder with
floating guide roller |
Rolling Press Machine Size |
About L1500mm*W600mm*H1500mm |
Total Installation Dimension |
L3000mm*W1200mm*H1300mm |
Power Supply |
110-380V 4KW |
Electric control |
With tension display, rolling speed display
function Electric motor revolution and connter
revolution |
