Cooling via radiator and cooling fan

Fixed high temperature alarm: 60°C

Digital Current Temperature display

Built in temperature alarm

• Φ 12mm PTC connector

• 8mm I.D, 12mm O.D. polyurethane tube is included

• 9 Liters made of stainless steel

• Water chiller should not be connected to a system with the capacity more than the tank's capacity itself.

• Use coolant  instead of water for longer service life.

• Do not use deionized water as the cooling agent, DI water may cause the copper pipe to corrode, mainly pitting, and leak over time.

• CE approval

• This chiller is using thermolysis cooling method. Thus, the chiller can't cool the temperature lower than ambient temperature. (e.g the room temperature is 14 °C. The minimum temperature cooled by the chiller is 14 °C). Please consider the KG5000 water chiller if you want the temperature to be lower than ambient temperature.
• Must use.  Rust Protection coolants to prevent rust and corrosion The use of tap water is prohibited.
• Please connect the chiller water outlet to the equipment water inlet, and the chiller water inlet to the equipment outlet. Otherwise, the water flow sensor on the equipment may fail to work due to wrong water flow direction
