CR2032 Coin/Button Cell Crimper Crimping Machine for Coin Cell Pilot Machine
Model Number:
TMAX-JK-KF20-TCDimension(L*W*H):
232 X 190X 330mmNet Weight:
30kgCompliance:
CE CertifiedWarranty:
1 yearMOQ:
1Payment:
L/C D/A D/P T/T Western UnionDelivery Time:
5 days
- WhatsApp : +86 13174506016
- Email : David@tmaxcn.com
- Email : Davidtmaxcn@gmail.com
- Wechat : 18659217588
Previous:
Laboratory Precision Coin Cell Battery Disc Cutter MachineNext:
Laboratory Coin Cell Disc Cutter with Standard 16, 19, 20 Dia. Cutting Die & 3 - 24mm Optional
CR2032 Coin/Button Cell Crimper Crimping Machine for Coin Cell Pilot Machine
TMAX-JK-KF20-TC is a newly designed CE Certified CR2032 Coin/Button Cell Crimper with lighter weight and a smaller footprint. The Crimper/Disassembling/Press die is suitable for Crimper/Disassembling/Press die various types of coin cells, such as CR2032, CR2025, and CR2016, without destroying the internals of the cell in order to study the materials inside. It can also disassemble CR2325, CR2450, and other special size cases with optional die sets. In addition, customers can easily replace the original die for crimping purpose. TMAX-CX120 is designed for operations outside a glove box.
SPECIFICATIONS:
Features |
Heavy duty steel frame PTFE Anti-Corrosion Core prevents coin cells from being short-circuited |
Crimping Die |
Optional die available from product option for crimping CR20XX, CR12XX, CR23XX, CR24XX, AG3, AG5 |
Pressure |
· Max. 8 metric Tons hydraulic pump with automatic pressure relief · Max.200 Kg/cm2 on CR20XX series coin cell |
Warranty |
2 years limited manufacturer warranty with lifetime support. |
Product Dimensions |
223mm X 170mm X 325mm |
Compliance |
CE Certified |
Net Weight |
25 kg |
|
Attention: The built-in small hydraulic pump is not designed for holding high pressure. The pressure inside will be released gradually after reaching 50~80 Kg/cm^2, (which is sufficient for disassembling the coin cell). |
