Automatic Spot Welder

18650 Battery Automatic Spot Welder

  • Model Number:

    TMAX-autospot1
  • Input Power:

    15KW
  • Net Weight:

    68kg
  • Compliance:

    CE Certified
  • Warranty:

    Two years limited warranty with lifetime technical support
  • MOQ:

    1
  • Payment:

    L/C D/A D/P T/T Western Union
  • Delivery Time:

    5 days
Product Details


18650 Battery Automatic Spot Welder


Product information:

TMAX-autospot1 Programmed automatic spot welder is an automatic spot welding machine for 18650 rotating

cylindrical battery or approximately rectangular type, or the ranks of regularly arranged single battery

welding combination. Only need to set up a few key parameters can be completed automatically welding function,

mainly used for the battery pack of a large number of batteries, widely used in power battery production.


Functional characteristics:

1.Programmable automatic welding, programming is simple and easy to learn, only need to control the

coordinates of a few parameters can be set to achieve automatic welding.

2.It has the function of automatic welding quality, which greatly improves the quality of welding.

3.The first overall design, set welding power supply and X, Y axis drive control in one, making the whole

 machine is simple, reliable, easy to use.

4.X, Y axis is equipped with a limit device, the protection of the motor beyond the limited range.

5.The high frequency inverter power supply, strong joints, no black.

6.Rack using the Longmen body, the appearance of beautiful atmosphere, compact.


Product Parameter :

Input Power

Output Power

Electrode Travel Range

Weld Reference Energy

Weight

AC220V±10%/50Hz

 15KVA

15mm

0-1024

68kg

Advance Weld Current

Up Time

Weld Current

Weld Time

Down Time

0-99.9%

0.0-9.9(mS)

0-99.9%

1.0-3.0mS

0-9.9mS

X Axis Weld Battery Space

Y Axis Weld Battery Space

Weld Point Space





0-99mm

0-99mm

0-9.9mm





Model

X Axis Travel
Range

Y Axis Travel Range

Z Axis Travel

Range

Dimension

TMAX-autospot1

0.0-200.0mm

0.0-300.0mm

0.0-15.0mm

1000×980×1450
