Temperature range

10℃～80℃

Humidity range

65%～98%R.H

Blackboard temperature

63℃、100℃（accuracy: ±3℃）

Temperature fluctuation

≤±1.5℃

Uniform temperature

≤±2.0℃

Humidity fluctuation

+2%～-3% R.H

Window filter

Borosilicate glass

Xenon light source

Imported air-cooled xenon arc light source

Xenon lamp power

1.8KW

Lamp Quantity

1

Rainfall time

1～9999min，continuous rainfall adjustable

Rainfall cycle

1-240 minutes, intermittent rainfall adjustable

Nozzle bore

Ф0.8mm(with ultra fine filter to prevent nozzle clogging)

Rain water pressure

 0.12～0.15kpa

Spray cycle

18min/102min or 12min/48min(spray time / no spray time)

Spray pressure

0.12～0.15Mpa

heating power

2.0KW

Humidification power

2KW

Light period

Continuous adjustable time 0-999 hours

Spectral wavelength

The irradiance range of 295nm-800nm is 100w-800W /㎡ adjustable.

Rotary speed

Adjustable rotation speed of the stage (stepless speed regulation)
