Inner box size

W400xD400xH450mm

Outer box size

W650xD920xH30mm

Temperature range

Normal temperature~200℃

Temperature display accuracy

0.1℃

Temperature stability

±1.0℃

Temperature uniformity

±2℃

Heating time

(5±2)℃/min, (average heating, non-linear no-load)

Temperature control meter

Programmable temperature controller, which can control the total heating time, which is different from ordinary temperature control meters.

Material of inner box

Stainless steel plate

Outer box material

Cold-rolled steel plate baking varnish

Insulation material

High-efficiency compressed glass wool

Heat preservation device

Non-fuse switch, over-temperature protection switch, fuse

Power supply

1∮, 220V, 20A

Safety device

Secondary over-temperature alarm, MCCB overload protection, etc.

Exhaust flue

Blade design can adjust the air volume

Control formation

When the temperature of the battery thermal shock test box reaches the set temperature, the time meter will be turned on automatically, and the heating power will be cut off when the time is reached, and the buzzer will prompt

Air circulation system

Convective air circulation system

Control system

When temperature is reached, stop when time is reached, buzzer prompts.
