Configuration factor

HS985-HW1-008B

Standard cooling capacity

KW
50Hz

17

Temperature control mode

Original three flowers solenoid valve, double solenoid valve interchangeable work, accurate temperature control

Temperature control range

High precision, hot and cold switch at will, temperature difference ± 0.1 ℃, 2-35 ℃ range of arbitrary adjustment

Power supply

V/ph/Hz

380/3/50

Operating power

KW
50Hz/60Hz

5.65

Maximum operating current

A

14.5

Refrigerant

Type

Imported DuPont R22 environmental protection refrigerant

Filling volume

3800g

Control method

Special pure red copper capillary interception cooling

Compressor

Type

Original Panasonic, Hitachi fully enclosed scroll type, service life up to 10-15 years or more

Power /KW

4.6

Features

Low energy consumption, ultra-quiet, fast temperature reduction

Condenser

Type

Self-developed production of water coolers special radiator, 100% pure red opper tubes with aluminium fins.

Features

Excellent heat dissipation, fast heat conduction, easy maintenance, energy consumption reduced by more than 30%.

Blower

Type

Original German imported EBM, Ember, Dunli external rotor axial blower

Features

Low noise, large air volume, low energy consumption, service life up to 10-15 years or more

Evaporator

Type

National standard food grade SUS304 stainless steel material production, stainless steel coil type heat transfer

Features

Good heat exchange effect, not easy to produce scale, easy to clean, never rusty

Volume

110L (water tank volume can be customised according to requirements)

Water pump

Type

Special SUS304 stainless steel water pump for chiller, service life up to 5-10 years or more

Features

Low energy consumption, ultra-quiet, high pressure, stable water pressure, never rusty

Power/Head

370W-2400W Head 28-70 metres

Water inlet and outlet

Stainless steel female thread

DN15/DN20/DN25, according to the needs of choice

Circulating water flow

35-150L/min

Thermostat

Self-developed microcomputer intelligent control system, ultra-clear LCD display, stable performance, precise control

Whole machine noise

≤115dB(A)

Safety protection

Compressor overheating protection, overload protection, high and low temperature protection, low pressure protection, low water level protection, phase sequence protection, leakage protection, water shortage protection.

Overall dimension

mm

L1150*W620*H1250

Weight

KG

225KG

Remarks: 1. Working range: chilled water temperature range 5 ℃ ~ 35 ℃, water temperature according to the use of self-setting.

2. Product configuration: a part of the accessories can be changed according to the customer's needs, in order to achieve the customer's needs.

The company reserves the right to change the above parameters or dimensions without notice.
