Project

Parameters

Resting method

Isobaric static or atmospheric static

Vacuum holding pressure

5KPA value change within 60S

Injection accuracy

Injection volume ≥125g±0.8%; Injection volume <125g±1g;

Production efficiency

≥12ppm

Qualification rate

≥99%

Crop rate

≥98%

Dimension

W10000 × L6500 x H2500mm

Weight/load

>750Kg/M2

Power supply

AC380V three-phase;voltage fluctuation±10%;power:20KW;frequency:50Hz

Compressed air

0.5~0.7Mpa ( 5~7kgf/cm2 ), dosage 600L/min

Model

TMAXZTHZYX-300

Cell height

90~220mm

Cell width

100~200mm

Cell thickness

20~80mm
