8 Channel Battery Analyzer (100mA - 20A up to 5V) with Software
Model Number:
TMAX-JC5V20AInput Power:
100WNet Weight:
30 Kg (65 lbs)Compliance:
CE CertifiedWarranty:
2 Year limited warranty with lifetime supportPlace of Origin:
Fujian, China (Mainland)Payment:
L/C D/A D/P T/T Western UnionDelivery Time:
5 days
- WhatsApp : +86 13003860308
- Email : David@tmaxcn.com
- Email : Davidtmaxcn@gmail.com
- Wechat : 18659217588
Previous:
Best 8 Channel Battery Analyzer (0.005 -1 mA, upto 5V) w/ Adjustable Cell Holders & Software - BST8-WANext:
Portable Internal Resistance & Open Circuit Voltage Tester for All Batteries 0 - 20V
8 Channel Battery Analyzer (100mA - 20A up to 5V) with Software
TMAX-JC5V20A is a eight-channel battery analyzer suitable for most applications in battery testing fields such as electrode materials research, battery performance & cycle test, small-scale battery formation, capacity grading, battery pack testing and etc.
1. Extended testing current range from 100mA~20A, up to 5V
2. Benefits from the implementation of four independent constant-current & voltage sources, each channel can function independently without interfering each other.
3. 16bit Bipolar ADC/DAC module enables the stable and accurate voltage sampling
4. Dynamic loading protection function prevents the cell & device from damaging by the surge current
SPECIFICATIONS:
Electricity Requirement |
208~240VAC 50/60Hz |
Power Consumption |
100W max. per channel |
Current |
1. Range: 100 mA –
20A programmable 2. Accuracy: ±(0.05%
RD + 0.1% FS) 3. Resolution: 1mA |
Voltage |
1. Range: 25mV - 5V
programmable 2. Accuracy: ±(0.05%
RD + 0.1% FS) 3. Resolution: 1mV 4. Minimum
Discharging Voltage: 2.5V |
Data sampling |
Time interval: >1s; |
Max. measurement cycles |
65535 cycles |
Max. program steps |
9999 steps |
Product Dimensions |
700mm W x 400mm D x 160mm H |
Channels & Test Modes |
Eight independent programmable channels. Each
channel can have different working modes and functions independently. 1. Working modes
Include: 2. Charge: constant
current charge (CC), constant voltage charge (CV), constant current constant
voltage charge (CCCV), constant power charge (CP), floating
charge, 3. Discharge: constant
current discharge (CD), constant power discharge (CP), constant resistance
discharge (CR) 4. Rest
& cycles |
Programs & Software Real-Time Mornitoring |
1. The software is
included to set various working modes for evaluating cell capacity and life
cycle for all types of rechargeable batteries 2. Limited
threshold conditions include voltage, current, time, capacity, negative
voltage slope, etc. 3. With real-time
monitoring windows and integrated graph/data windows, the testing process can
be observed more directly and efficiently 4. During the test,
the software will provide instructions and warnings for assistance |
Test Reports |
1. Various curves
can be created by software base on user definition. (Voltage-time curve,
current-time curve, capacity-voltage curve, loops times-charge/discharge
capacity curve, loops times-charge/ discharge efficiency curve, etc) 2. Data reports are
created by software (export to Excel or .txt). User can easily compare the
performance of the batteries tested in channels both visually and
statistically |
DCR Testability |
The DCR Testing feature enables the Hybrid Pulse Power Characterization
(HPPC) of the battery. Such function also provides the max/min
voltage and current protection. |
Protection and Auto-recover |
If a power failure occurs during testing, the
system will shut down all operating channels. Once power is recovered, the
system will automatically resume those stopped channels and ensure that the
test is normally conducted, so that no cases will lose any data. |
Compliance |
CE Certified |
Warranty |
Two years limited warranty with lifetime support
for the battery analyzer. |
Net Weight |
30 Kg (65 lbs) |
