Number of device channels

The whole machine has 256 channels in total

Workflow control mode

Whole cabinet control

Charging mode

Constant current and constant voltage

Charging cut-off conditions

Voltage, current, time, capacity

Discharge mode

Constant current

Discharge cut-off conditions

Voltage, time and capacity

Sampling inspection cycle

≤10s

Voltage measurement range

0~5V，

Resolution: 1mV

Battery voltage range

Charge：0~4.5V，

Discharge：4.5~2.5V

Constant voltage range

3~4.5V

Voltage accuracy

±（0.05%RD+0.1%FS）

Current range

Charge: 0.010-2A，

Discharge: 0.010-2A，

Resolution: 1mA

Current accuracy

±（0.1%RD+0.1%FS）

Time frame

Any setting within 0 ~ 30000 minutes, the time unit is min

Time accuracy

≤±0.1%

Fixture type

Four wire fixture

Fixture adjustable height

10mm-90mm

Support battery

Prismatic cell/cylindrical battery

Working power supply

AC380V±10%, 50HZ,

Power consumption: 4.5KW(three-phase four wire system)

Communication mode

RS485，Baud rate 57600

Overall dimension

720mm（L）×500mm（W）×1840mm（H）

work environment

Temperature：0-40℃，relative temperature≤85%

Full load operating current

The maximum phase line: 15A,

The maximum zero line: 3A

Equipment starting current

The closing moment of air switch is about 60A

Machine weight

About 100KG
