2000W 40KHz Ultrasonic Metal Spot Welder for Tab and Cap Welding of Cylindrical Battery
Model Number:
TMAX-VS-40AInput Power:
2000WCompliance:
CE CertifiedWarranty:
One years limited warranty with lifetime technical supportPayment:
L/C D/A D/P T/T Western UnionDelivery Time:
5 days
- WhatsApp : +86 13003860308
- Email : David@tmaxcn.com
- Email : Davidtmaxcn@gmail.com
- Wechat : 18659217588
Previous:
Lithium ion Battery Making Machine Solvent Processing System Waste Gas Treatment EquipmentNext:
21700 18650 32650 32700 26650 Cylindrical Lab Line Equipment Small Trial Line for Battery Research
2000W 40KHz Ultrasonic Metal Spot Welder for Tab and Cap Welding of Cylindrical Battery
Ⅰ、Features:
The 2000w battery welder can weld stacked electrode with 10-35 layers aluminum foil or copper foil with Al tab and Nickel tab.
Note:If you are not quite clear about what welder would be suitable for you,please consult the sales manager with following parameters,they will find a solution for you:
1. Weld material
2. Thickness of the material
3. Layer number of material
Ⅱ、Specifications:
Features |
Preset welding programs selectable for Al and Cu (Note: Welding power can be readjusted to fit the needs for welding other types of metals such as Au, Fe, Ni, Ag...). |
Input Voltage |
AC 110V or 220V +/-10%, 50/60Hz |
Max. Power2 |
2000W→can be customized |
Welding Area |
4mm(L) x 4mm(W)→can be customized |
Welding Head |
The welding heads and welding base are included for welding both aluminum & copper current collectors from 2 to 40 layers |
Ultrasonic Frequency |
24K Hz→can be customized |
Product Dimensions |
1. Controller: 360mm(L) x 480mm(W) x 200mm(H) 2. Welder: 200mm(L) x 460mm(W) x 270mm(H) |
Net Weight |
70kg |
Compliance |
CE Certificate |
Warranty |
One Year limited warranty with lifetime support |
| Recommendation | For the pouch cell assembly, we also recommend you the following items: Forming machine Hot sealer with tab Vacuuming seal
Stacking machine Die Cutter Aluminum Laminated Film |
