Max Pressure

· 15 metric tons

· Pressure gauge is built in

Pressure Gauge

· Gauge displays force in both PSI and Bar units for versatility (click picture on left to enlarge)

· Please follow the Force Conversion table below  to obtain the equivalent force (in Tonnes unit) applied on the Hydraulic Cylinder according to the pressure gauge

Max Lifting Height of Bottom Cylinder

13 mm

Top Support Screw Adjustable Height

215 mm

Protection Cover (Included)

· Polycarbonate Safety Shield ( click the picture on left) is included with the press to protect the user from fragmentations.

· The harness on shield allows the door to be buckled down securely during use and opened easily.

Dimensions of Machine
& Working Space

· 330mm(L) x 190mm(W) x 410mm(H)

· D1: 120mm   D2: 70mm D3: 124mm H1: 180mm   H2: 155mm

Length of Press Rocker

250mm

Net Weight

20 Kg ( 44 lbs)

Dimensions of Shipment

24"x10"x10"

Weight of Shipment

60 lbs

Warranty

· One year limited standard warranty (Extended 5-year warranty is available at extra cost)

Compliance

· CE Certified

Application Notes

· Warning: Customers must always wear protection goggles during operation inoutside glovebox

· Do not raise the bottom cylinder (piston) more than it's maximum traveling distance. (13 mm)

· This compact press  can be placed inside various glove boxes to press air sensitive materials under inert gas
